Sterling Power PCU1240plus – Pro Charge Ultra Plus 12V 40A Battery Charger
Quantity:
Choose options
Quantity:
The Sterling Power PCU1240plus is a 12V 40A mains battery charger from the Pro Charge Ultra Plus range — a compact, switch-mode charger built to keep 12V banks properly topped up from shore power or a generator. It delivers a full multi-stage charge rather than a crude constant voltage, so lead, AGM, gel, and lithium banks are charged correctly and held at the right float.
Pro Charge Ultra Plus models add selectable battery profiles (including lithium), advanced diagnostics, and remote-control capability via the PCUR remote.
Charging Specifications
| Type | AC-input multi-stage battery charger (Pro Charge Ultra Plus) |
|---|---|
| Nominal output voltage | 12V |
| Max output current | 40A |
| AC input | 80–270V AC, 40–70Hz |
| Power factor / efficiency | Power Factor 0.976 @ 230V; full-load current ≈4.6A @ 230V; Efficiency 90.4% |
| Charge profile | Multi-stage (bulk, absorption, float) |
| Charging profiles | 11 pre-programmed profiles (AGM, Gel, lead-acid, LiFePO4) plus 4 user-customizable profiles |
| Battery types | Lead-acid, AGM, gel, and lithium |
| Remote | Compatible with the optional PCUR remote control, mountable up to 30 ft away |
| Dimensions, weight & outputs | 260 × 215 × 90mm; 2.0kg; 3 isolated charging outputs/banks |
| Ingress protection | IP22 splash/drip protection; ABYC drip-test compliant |
| Certifications | UL certification available |
| Recommended generator size | ≈1200W for cold start (unit draws ≈600W running) |
| Warranty | 5-year warranty |
Key Features
- 12V 40A multi-stage mains charging
- Selectable profiles for lead-acid, AGM, gel, and lithium — 11 pre-programmed profiles plus 4 user-customizable
- 3 isolated charging outputs/banks
- Remote monitoring and control via the optional PCUR remote, mountable up to 30 ft away
- Automatic desulphation cycle approximately every 7–10 days
- Dual/redundant high-voltage protection — primary digital plus secondary independent analog backup circuit
- Temperature compensation via battery sensor with high-temperature trip shutdown
- 32-LED information display with digital voltage/current meters and reserve-capacity power meter
- Thermostatically controlled, variable-speed forced-draft cooling fan
- Conformal-coated PCBs rated for humid, salt-air marine environments
